Lian Li EDGE Gold Series ATX 3.1 PCIe 5.1 Fully Modular L-Shape | Black | White Power Supply

Revolutionary L-Shape Design for Dual Chamber Architecture

The Lian Li EDGE Gold Series establishes a new standard in power supply engineering with its innovative L-shape form factor. Designed specifically for modern dual-chamber chassis, such as the O11 series, this unique orientation solves a long-standing issue in PC building: cable clearance. By reorienting the modular connector panel outward, the EDGE Gold ensures that users have direct, unobstructed access to plug in cables even after the PSU is installed. This vertical installation method drastically simplifies cable management, making it accessible for builders of all skill levels and eliminating the struggle of tight bends and inaccessible ports found in traditional side-mounted PSU designs.

Industrial-Grade Efficiency and Reliability

Built to deliver unwavering performance, the EDGE Gold series is certified 80 PLUS Gold, Cybenetics Platinum (on 1000W/1200W models), and PPLP Gold. At the heart of this efficiency lies a robust internal architecture featuring top-end German EPCOS industrial-grade capacitors and high-quality Japanese capacitors. These components provide superior resistance to harsh temperatures and environmental stress, ensuring longevity and stability. Comprehensive protection circuits, including OCP, OVP, SCP, OPP, UVP, OTP, and Surge Intensity Protection, guard your valuable hardware against power anomalies, while an Inrush Current Limiter guarantees stable startups every time.

Next-Generation PCIe 5.1 and ATX 3.1 Power

Future-proof your build with full support for the latest ATX 3.1 and PCIe 5.1 standards. The EDGE Gold series features Lian Li’s in-house researched and developed 12V-2×6 connectors. Unlike standard headers, these utilize alloy copper soldered terminals and increased copper thickness (0.25mm) to dramatically reduce contact resistance. The dual-color connector housing provides a vital safety feature, allowing builders to visually confirm a secure, flush connection. The 1200W model specifically includes an extra dual 8-pin to 12V-2×6 cable, ready to feed the most power-hungry next-gen GPUs.

Exclusive EDGE HUB: Centralized Control (1000W & 1200W Models)

For the 1000W and 1200W models, Lian Li introduces the world’s first PSU with a detachable USB and PWM fan hub. This modular hub can be mounted directly to the PSU unit or placed anywhere inside the case using its integrated magnetic backing. It expands your connectivity with four internal USB 2.0 headers (supporting up to 8 downstream devices) and six PWM fan headers. This solution declutters motherboard connections and centralizes control for RGB controllers and cooling fans. The hub is powered directly by the PSU for stable power delivery or can be powered independently via a PCIe 8-pin connector when detached.

Premium Braided Cables and Thermal Performance

Aesthetics meet functionality with fully modular cables that feature a premium braided texture right out of the box. Key cables, including the 20+4 pin, CPU, and PCIe connectors, come with pre-installed cable combs, allowing for clean, professional curves and organized runs without the need for aftermarket extensions. To support these versatile builds, the cable lengths have been extended, ensuring they reach every component easily in both dual-chamber and large tower chassis. Cooling is managed by a 120mm FDB fan optimized for silence, protected by a highly porous (66.9%) magnetic mesh dust filter that is easily removable for cleaning, ensuring your system runs cool and dust-free for years to come.
