Cooler Master Elite 690 Mid-Tower ATX Case Black Wood Tempered Glass USB 3.2 Gen 2×2 Type-C – E690-KHNN-S00
Original price was: ₱4,010.00.₱3,495.00Current price is: ₱3,495.00.
- Black mid-tower ATX case with real wood front and 270-degree tempered glass panels
- Vertical cooling supports up to 10 fans and dual 360mm radiators
- Pre-installed 3x ARGB PWM fans with sync and USB 3.2 Gen 2×2 Type-C
- GPU ready up to 425mm for RTX 50-series compatibility
- Optimized PSU chamber and mesh vents for superior airflow and cable routing
- Accommodates ATX motherboards with 170mm CPU cooler clearance
- SKU: E690-KHNN-S00
Out of stock
Restock & Price Alerts
We'll email you the moment this is back in stock. If you enter a target price, we'll also send you a separate alert if the price drops to your goal later!
Want to track and manage your alerts? Sign in or create an account.
-
Authorized
Dealer -
Nationwide
Shipping -
Store &
RMA HUB -
Expert
Support -
7-Day DOA
Protection -
Community
Trusted -
Turnstile
Protected -
reCAPTCHA
Secured -
Tested &
Verified
The Cooler Master Elite 690 Mid-Tower ATX Case in black masterfully fuses natural elegance with cutting-edge performance through its genuine wood-accented front panel paired with dual tempered glass sides for a 270-degree panoramic view that highlights internal components and lighting in style-conscious builds, while the vertical cooling architecture and dedicated PSU chamber optimize airflow separation and cable management for sustained high-load operations in gaming or professional environments. Supporting up to ten fans including three pre-installed ARGB PWM units with motherboard sync capabilities, it accommodates massive 360mm radiators on top and bottom alongside NXT-gen GPUs up to 425mm, ensuring readiness for future hardware like RTX 50-series cards with exceptional thermal headroom via mesh ventilation on multiple panels. High-speed connectivity shines with USB 3.2 Gen 2×2 Type-C delivering 20Gbps transfers, complemented by versatile storage for up to two 3.5-inch and 2.5-inch drives each in a compact 42.93L chassis that balances form and function, making it an ideal enclosure for enthusiasts seeking immersive aesthetics, efficient cooling, and seamless upgrades backed by a 2-year warranty.
| Specification | Details |
|---|---|
| SKU | E690-KHNN-S00 |
| Brand | Cooler Master |
| Product Name | Elite 690 Mid-Tower ATX Case |
| Model Number | E690-KHNN-S00 (Black) |
| Color | Black |
| Materials | Front Panel: Tempered Glass + Wood; Left Side: Tempered Glass; Right Side: Steel |
| Dimensions (Incl. Protrusions) | 434 x 218 x 454 mm |
| Volume | 42.93 L |
| Motherboard Support | ITX, Micro-ATX, ATX |
| Power Supply Support | ATX |
| Expansion Slots | 7 |
| Drive Bays | 1x 3.5" (Max. 2), 1x 2.5" (Max. 2) |
| I/O Panel | 1x USB Type-C 20Gbps, 2x USB 3.0, 1x 3.5mm Combo Audio Jack |
| Pre-installed Fans | Rear: 1x 120mm ARGB PWM; Side: 2x 120mm ARGB PWM Reverse |
| Fan Support | Top: 2x 140mm / 3x 120mm; Rear: 1x 120mm; Side: 2x 120mm; Bottom: 3x 120mm |
| Radiator Support | Top: 120/240/360mm (Max height 45mm); Bottom: 120/240/360mm; Side: 120/240mm |
| Clearances | CPU Cooler: 170mm; PSU: 250mm; GPU: 425mm |
| Warranty | 2 Years |
| Weight | 5.1 kg |
|---|---|
| Dimensions | 46 × 23 × 42 cm |
| Brand | Cooler Master |
