Technical Spec:
Product Dimensions: 144×147×164 mm (L×W×H)
Heatsink Dimensions: 140×110×160 mm (L×W×H)
Net Weight: 1575 g
Heatpipe: Ø6 mm×7 pcs
Fan Dimensions: 140×140×25 mm (L×W×H) / 120×120×25 mm (L×W×H)
Fan Speed (Performance Mode): 500~1700 RPM±10%
Fan Airflow (Performance Mode): 79.1 CFM / 58.06 CFM
Fan Air Pressure (Performance Mode): 2.44 mmAq / 2.1 mmAq
Overall Noise (Performance Mode): ≤29.3 dB(A)
Fan Speed (Quiet Mode): 500~1350 RPM±10%
Fan Airflow (Quiet Mode): 63.76 CFM / 46.75 CFM
Fan Air Pressure (Quiet Mode): 1.58 mmAq / 1.35 mmAq
Overall Noise (Quiet Mode): ≤22.6 dB(A)
Fan Connector: 4-pin PWM
Bearing Type: Fluid Dynamic Bearing
Motor Type: 6-Pole Fan Motor
Fan Rated Voltage: 12 VDC
Fan Rated Current: 0.1 A / 0.07 A
Fan Power Consumption: 1.2 W / 0.84 W
Rated Voltage: 12 VDC
Power Consumption (Performance Mode): 2.88 W
Power Consumption (Quiet Mode): 1.56 W
EAN: 6933412728092
P/N: R-ASN4-BKNNMT-G
