Epson LQ-2190 24-Pin 136 Column Wide Carriage Dot Matrix Impact Printer – C11CA92051
Original price was: ₱49,450.00.₱43,000.00Current price is: ₱43,000.00.
- 24-Pin Impact Head: Delivers sharp, clear text and professional output for up to 136 columns.
- Blazing Print Speeds: Processes high-volume tasks rapidly with speeds up to 480 cps at 10 cpi.
- Massive Form Capability: Effortlessly prints through multi-part forms with 1 original and 5 copies.
- Extreme Durability: Rated for a 20,000 POH MTBF and a printhead life of 400 million strokes per wire.
- Economical Operation: High-yield ribbon provides up to 15 million characters for reduced consumable costs.
- Flexible Loading: Choice of front, rear, and bottom paper paths for optimized media handling.
- Dual Interface Connectivity: Built-in High-Speed USB 2.0 and Parallel ports as standard.
- Integrated 128 KB Buffer: Ensures smooth data processing and prevents document bottlenecks.
- SKU: C11CA92051
In stock
Price Drop Alerts & Price History
-
Authorized
Dealer -
Nationwide
Shipping -
Store &
RMA HUB -
Expert
Support -
7-Day DOA
Protection -
Community
Trusted -
Turnstile
Protected -
reCAPTCHA
Secured -
Tested &
Verified
Unparalleled Performance for Demanding Business Workflows
The Epson LQ-2190 Dot Matrix Printer is a 24-pin, 136-column powerhouse engineered specifically to thrive in high-pressure office environments. Designed to deliver a combination of exceptional speed and rugged reliability, this wide-carriage impact printer is the definitive choice for businesses processing significant volumes of data, such as inventory manifests, complex financial reports, and large-scale invoicing. With a blazing print speed reaching up to 480 characters per second at 10 cpi, the LQ-2190 drastically improves productivity by ensuring that document queues move quickly and smoothly.
Industrial-Grade Reliability and Low Cost of Ownership
Built as a workhorse for medium and large print volumes, the LQ-2190 boasts a Mean Time Between Failure rating of 20,000 power-on hours. This robust architecture is further complemented by a printhead life capable of 400 million strokes per wire, minimizing the need for frequent servicing and reducing downtime. The high-yield black fabric ribbon is rated for approximately 15 million characters, which translates to longer replacement intervals and a significantly lower total cost of ownership over the printer’s extensive lifespan. Businesses can rely on this machine for uninterrupted operations day after day.
Exceptional Versatility in Media and Connectivity
Flexibility is at the core of the LQ-2190 design. It offers a wide array of paper handling options, including front, rear, and bottom paper paths, allowing users to manage their desk space more effectively while catering to different media requirements. The printer handles diverse substrates with ease, from single cut sheets and envelopes to multi-part forms consisting of one original and five copies. This adaptability is matched by its connectivity suite, which includes integrated USB 2.0 and Parallel interfaces as standard. For offices requiring shared access, an optional Type-B internal network print server can be added to facilitate seamless communication across a local area network.
Precision Control and Modern Software Integration
The intuitive control panel, featuring six switches and ten LED indicators, provides immediate feedback and easy configuration directly from the hardware. For more granular control, the included Epson Status Monitor 3 and Printer Setting Utility allow administrators to monitor status and adjust preferences directly from a Windows-based PC. Supporting everything from classic italic tables to modern barcodes like EAN-13 and Code 128, the LQ-2190 integrates into existing digital infrastructures effortlessly. Its bi-directional logic-seeking print direction ensures that the carriage finds the most efficient path across the page, maximizing every second of operation.
| Epson LQ-2190 Dot Matrix Printer Specifications | |
|---|---|
| Core Printing Technology | |
| Print Method | Impact dot matrix |
| Number of Pins | 24 pins |
| Print Direction | Bi-direction with logic seeking |
| Control Code | ESC/P2 and IBM PPDS emulation |
| Carriage Width | 136 Columns (Wide Carriage) |
| Print Speed & Throughput | |
| High Speed Draft | 10 cpi: 480 cps 12 cpi: 576 cps |
| Draft Speed | 10 cpi: 360 cps | 12 cpi: 432 cps | 15 cpi: 540 cps Condensed (17/20 cpi): 308 / 360 cps |
| Letter Quality (LQ) | 10 cpi: 120 cps | 12 cpi: 144 cps | 15 cpi: 180 cps Condensed (17/20 cpi): 205 / 240 cps |
| Durability & Reliability | |
| MTBF | 20,000 Power On Hours (POH) (at 25% Duty) |
| MVBF | 40 million lines (except print head) |
| Printhead Life | 400 million strokes per wire |
| Ribbon Life | Approx. 15 million characters (Black Fabric) |
| Media Handling & Paper Paths | |
| Paper Feed Paths | Manual Insertion: Front or Rear In, Top out Push Tractor: Front or Rear In, Top out Pull Tractor: Front or Rear or Bottom in, Top out |
| Multi-part Forms | 1 Original + 5 Copies |
| Media Width Support | 100mm to 420mm (Cut sheet); 101.6mm to 406.4mm (Continuous) |
| Special Media | Envelopes (No.6 & No.10), Labels (Base sheet), Cards, Roll Paper |
| Connectivity & Interface | |
| Standard Interfaces | Bi-directional Parallel (IEEE-1284 nibble mode), USB 2.0 (Full Speed) |
| Expansion Slot | Type B I/F Level 2 (Optional Network Print Server) |
| Supported OS | Microsoft Windows 2000, XP, Vista, 7, 8, 8.1, 10 |
| Physical Attributes | |
| Dimensions (W x D x H) | 639 x 402 x 256 mm |
| Weight | 13 kg |
| Acoustic Noise | 54 dB |
| Memory Buffer | 128 KB |
| Weight | 15.48 kg |
|---|---|
| Dimensions | 75 × 52 × 29 cm |
| Brand | Epson |
