Fractal Design Celsius+ S24 Prisma AIO Cooler 240mm Radiator ARGB Fans – Celsius+ S24 Prisma Water Cooling Unit
Original price was: ₱9,600.00.₱8,395.00Current price is: ₱8,395.00.
- 240 mm AIO cooler with two Prisma AL-12 PWM ARGB fans (500-2000 RPM)
- Supports Intel (1700*, 1851*, 1200, 115X, 1366, 2011, 2066) and AMD (AM2, AM3, AM4, AM5, FM1, FM2)
- Copper coldplate, ceramic-bearing pump (800-2800 RPM, 20 dBA)
- 85.71 CFM, 14.4 kPa pressure, dual-mode (Auto/PWM) control
- 400 mm braided tubes, 5-year warranty (*LGA 1700 needs updated bracket)
In stock
Price Drop Alerts & Price History
-
Authorized
Dealer -
Nationwide
Shipping -
Store &
RMA HUB -
Expert
Support -
7-Day DOA
Protection -
Community
Trusted -
Turnstile
Protected -
reCAPTCHA
Secured -
Tested &
Verified
Fractal Design Celsius+ S24 Prisma AIO Cooler
The Fractal Design Celsius+ S24 Prisma AIO Cooler delivers high-performance liquid cooling with vibrant ARGB lighting. Featuring a 240 mm aluminum radiator and two Prisma AL-12 PWM ARGB fans (500-2000 RPM, 85.71 CFM), it ensures efficient heat dissipation. The copper coldplate with pre-applied thermal paste supports Intel (1700*, 1851*, 1200, 115X, 1366, 2011, 2066) and AMD (AM2, AM3, AM4, AM5, FM1, FM2) sockets (*LGA 1700 requires updated bracket). The ceramic-bearing pump operates at 800-2800 RPM (up to 3500 RPM in thermal protection mode above 60°C), delivering up to 14.4 kPa pressure with low noise (20 dBA). Low-permeability rubber tubes with braided nylon sleeves and articulating 90-degree fittings enhance durability and flexibility. Dual-mode fan control (Auto/PWM) offers customizable performance. With a 5-year warranty and a sleek design, this cooler is ideal for enthusiasts seeking powerful cooling and aesthetics.
| Specification | Details |
|---|---|
| Brand | Fractal Design |
| Model | Celsius+ S24 Prisma |
| Sockets Supported (Intel) | 1700*, 1851*, 1200, 1150, 1151, 1155, 1156, 1366, 2011, 2011-3, 2066 (*Compatible using updated LGA 1700 bracket, contact Fractal support) |
| Sockets Supported (AMD) | AM2, AM2+, AM3, AM3+, AM4, AM5, FM1, FM2, FM2+ |
| Coldplate Material | Copper |
| Thermal Paste | Pre-applied |
| Tube Length | 400 mm |
| Tube Material | Low-permeability rubber with braided nylon sleeve |
| Fittings, Block Side | Articulating 90-degree elbow |
| Fittings, Radiator Side | Straight rotary |
| Fan Control | Dual mode (Auto/PWM) |
| Note | Not compatible with the Adjust R1 |
| Fan Type | Prisma AL-12 PWM ARGB |
| Fan Rotational Speed | 500 – 2000 RPM |
| Fan Bearing | LLS |
| Fan PWM Control | Yes |
| Fan Acoustical Noise (Full Speed) | 32.7 dBA |
| Fan Maximum Air Flow | 85.71 CFM |
| Fan Maximum Static Pressure | 2.78 mm H2O |
| Fan Input Voltage | 12V DC |
| Fan Maximum Input Current | 0.18A |
| Fan MTBF | 100,000 hours |
| Pump Rotational Speed | 800-2800 RPM (normal), 3500 RPM (thermal protection mode above 60°C) |
| Pump Bearing Type | Ceramic bearing and shaft |
| Pump PWM Control | Yes |
| Pump Acoustical Noise (Full Speed) | 20 dBA |
| Pump Maximum Pressure | 14.4 kPa / 1.46 mm H2O / 2.0 PSI |
| Pump Input Voltage | 12V DC |
| Pump Input Current (Without Fans) | 0.36A |
| Pump MTTF | 50,000 hours |
| Block Height | 45 mm |
| Block Measurements (With Fittings) | 86 x 75 mm |
| Block Diameter (Main Block Body) | 62 mm |
| Radiator Dimensions | 122 x 31 x 284 mm |
| Radiator Housing Material | Aluminum |
| Radiator Fin Material | Aluminum |
| Fan Screw Threads | 6-32 |
| Package Contents | Celsius+ S24 unit, 2x 120 mm fans, User manual, Mounting hardware for all listed sockets, Fan and radiator mounting screws |
| Package Dimensions | 411 x 180 x 145 mm |
| EAN | 7340172702108 |
| UPC | 843276102104 |
| JAN | 4537694275545 |
| Product Code | FD-W-2-S2402 |
| Warranty | 5 years |
| Packaging Weight | 2 kg |
|---|---|
| Packaging Dimensions (L×W×H) | 35 × 25 × 15 cm |
| Brand | Fractal Design |
