GIGABYTE B760M DS3H AX DDR5 Motherboard, Intel B760 Chipset, LGA 1700 Socket, Micro-ATX Form Factor – GA-B760M-DS3H-AX


- Supports Intel 12th, 13th, and 14th Gen processors with LGA 1700 socket for powerful performance.
- DDR5 memory support up to 7600 MT/s, with up to 256GB capacity for seamless multitasking and fast speeds.
- Dual PCIe 4.0 slots and dual M.2 connectors for high-speed storage and expandability.
- Realtek 2.5GbE LAN and Wi-Fi 6E for ultra-fast connectivity and stable wireless performance.
- Triple display support with HDMI and DisplayPort outputs for enhanced productivity or gaming setup.
- Easy BIOS management with Q-Flash Plus for smooth firmware updates.
Description
Enhance your computing experience with the GIGABYTE B760M DS3H AX motherboard, featuring the advanced Intel B760 chipset and designed for high-performance setups. With support for Intel’s latest 12th, 13th, and 14th generation processors through the LGA 1700 socket, this motherboard ensures seamless multitasking and gaming performance. The high-speed DDR5 memory support, capable of up to 7600 MT/s, allows you to run demanding applications and heavy workloads effortlessly. You’ll experience faster boot times and improved performance, whether you’re playing the latest games or working on intense projects.
This motherboard also supports PCIe 4.0, offering increased data transfer rates for graphics cards and NVMe SSDs, enabling faster rendering and load times. Integrated Intel HD Graphics and multiple display outputs, including HDMI and DisplayPort, support triple display setups for multi-tasking or immersive gaming. Realtek 2.5GbE LAN and Wi-Fi 6E connectivity provide ultra-fast network speeds, while Bluetooth 5.3 ensures a smooth and stable wireless experience.
For those looking to enhance their system further, the GIGABYTE B760M DS3H AX motherboard offers excellent expandability with ample PCIe slots and M.2 storage connectors. The back panel features a USB Type-C port for fast data transfers, while internal headers provide additional connectivity options. Easy BIOS management through Q-Flash and Q-Flash Plus further ensures a hassle-free experience, making this motherboard a fantastic choice for enthusiasts looking to build a powerful and future-proof PC.
Specification | Details |
---|---|
CPU Support | LGA1700 socket: 14th, 13th, and 12th Gen Intel Core, Pentium Gold, and Celeron Processors. L3 cache varies by CPU. |
Chipset | Intel B760 Express Chipset |
Memory Support | Supports DDR5 up to 7600(O.C.), 4 x DIMM sockets, up to 256 GB, Dual channel, ECC and non-ECC memory support |
Onboard Graphics | Intel HD Graphics, 1 x HDMI port (4096x2160@60Hz), 2 x DisplayPort (4096x2304@60Hz), support for triple display. |
Audio | Realtek Audio CODEC, 2/4/5.1/7.1 channel, S/PDIF Out |
LAN | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Wireless Communication | AMD Wi-Fi 6E RZ608, Intel Wi-Fi 6E AX210/AX211, Bluetooth 5.2/5.3, up to 2.4 Gbps data rate |
Expansion Slots | 1 x PCIe x16 slot (PCIe 4.0), 2 x PCIe x1 slots (PCIe 3.0) |
Storage Interface | 1 x M.2 PCIe 4.0 x4, 1 x M.2 PCIe 4.0 x4, 4 x SATA 6Gb/s, RAID 0/1/5/10 support |
USB Ports | 1 x USB Type-C 3.2 Gen 2, 5 x USB 3.2 Gen 1, 2 x USB 2.0/1.1 on back panel, 4 x USB 2.0 headers internal |
Back Panel Connectors | 2 x USB 2.0/1.1, 1 x PS/2 port, 2 x SMA antenna connectors, 1 x HDMI, 2 x DisplayPort, 3 x USB 3.2 Gen 1, 1 x USB Type-C, 1 x RJ-45, 3 x audio jacks |
Operating System | Supports Windows 10/11 64-bit |
Form Factor | Micro ATX, 24.4cm x 24.4cm |
Additional information
Weight | 1.7 kg |
---|---|
Dimensions | 31 × 29 × 8 cm |
Brand | Gigabyte |
Socket | LGA 1700 CPU |
Desktop RAM | DDR5 |
