GIGABYTE B860M GAMING X Motherboard, Intel Core Ultra Support, DDR5, PCIe 5.0, High-Speed Networking – GA-B860M-GAMING-X


- Supports Intel® Core™ Ultra Processors (LGA1851 socket)
- Up to 256GB DDR5 memory, with speeds up to 9200(O.C) MT/s
- Triple-display support with USB4® Type-C®, DisplayPort 2.1, HDMI 2.1
- Realtek® 2.5GbE LAN for fast connectivity
- PCIe 5.0 x16 and PCIe 4.0 x4 expansion slots
- M.2 and SATA storage, with RAID support
- Multiple USB ports, including USB4® Type-C®
Description
The GIGABYTE B860M GAMING X MOTHERBOARD delivers exceptional performance for Intel® Core™ Ultra processors with a robust Intel® B860 Express Chipset. Offering support for up to 256GB of DDR5 memory with blazing speeds up to 9200(O.C) MT/s, this motherboard is perfect for gaming and professional workloads that demand the best in speed and reliability.
Enjoy high-definition graphics with its integrated Intel® HD Graphics Processor, supporting up to triple-display setups. With support for USB4® Type-C®, DisplayPort 2.1, and HDMI 2.1, your visual experience is smooth and vibrant, capable of resolutions up to 4K. The Realtek® 2.5GbE LAN chip ensures fast and stable connectivity, making this motherboard a great choice for gamers and content creators who need high bandwidth and low latency.
For expansion, the motherboard features PCIe 5.0 x16 and PCIe 4.0 x4 slots, supporting the latest graphics cards and NVMe SSDs. Storage options are plentiful with M.2 and SATA connections, supporting RAID configurations for redundancy and speed. The motherboard also provides excellent connectivity options with a variety of USB ports and a USB4® Type-C® port, ensuring that all your peripherals work seamlessly.
The GIGABYTE B860M GAMING X MOTHERBOARD is an excellent choice for users looking for a high-performance, future-proof motherboard to power their next-gen systems.
Specification | Details |
---|---|
Model | GIGABYTE B860M GAMING X |
CPU Support | LGA1851 socket: Supports Intel® Core™ Ultra Processors (refer to GIGABYTE's website for the latest CPU support list) |
Chipset | Intel® B860 Express Chipset |
Memory | 4 x DDR5 DIMM sockets, up to 256GB, Dual-channel architecture, Support for ECC and non-ECC un-buffered DIMMs, Support for Extreme Memory Profile (XMP) modules, DDR5 up to 9200(O.C) MT/s |
Onboard Graphics | Integrated Intel® HD Graphics Processor, USB4® Type-C®, DisplayPort 2.1, HDMI 2.1, Supports triple-display |
Audio | Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel support |
LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Expansion Slots | 1 x PCIe 5.0 x16 slot (CPU), 1 x PCIe 4.0 x4 slot (Chipset) |
Storage Interface | 1 x M.2 PCIe 5.0 x4 (CPU), 1 x M.2 PCIe 4.0 x4 (Chipset), 4 x SATA 6Gb/s connectors, RAID 0, RAID 1, RAID 5, RAID 10 support for SATA |
USB Ports | 1 x USB4® Type-C® (CPU), 1 x USB Type-C® (Chipset), 5 x USB 3.2 Gen 1, 9 x USB 2.0/1.1 ports |
Internal I/O Connectors | 24-pin ATX main power, 8-pin ATX 12V, CPU fan header, 3 x addressable RGB LED strip headers, M.2 connectors, SATA connectors, front panel headers, TPM connector |
Back Panel Connectors | 1 x HDMI, 1 x DisplayPort, 1 x USB4® Type-C®, 3 x USB 3.2 Gen 1, 5 x USB 2.0/1.1, 1 x RJ-45 LAN port, 3 x audio jacks |
I/O Controller | iTE® I/O Controller Chip |
H/W Monitoring | Voltage, temperature, fan speed, and water cooling flow rate detection |
BIOS | AMI UEFI BIOS |
Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
Operating System | Windows 11 64-bit |
Form Factor | Micro ATX, 24.4cm x 24.4cm |
Additional information
Weight | 1.7 kg |
---|---|
Dimensions | 31 × 29 × 8 cm |
Brand | Gigabyte |
Socket | LGA 1851 CPU |
Desktop RAM | DDR5 |
