GIGABYTE Z890 Eagle Wi-Fi 7 LGA 1851 ATX Motherboard, Intel Z890 Chipset, 4x DDR5 DIMM Slots, Up to 256GB Max Memory, Wi-Fi 7 & BT 5.4, 1x PCIe 5.0 x16, 4x M.2 Slots – GA-Z890-EAGLE-WIFI7


- Supports Intel® Core™ Ultra Processors with LGA 1851 socket for cutting-edge performance.
- DDR5 memory support up to 9200 MHz, with 4 DIMM slots, up to 256GB total memory.
- PCIe 5.0 x16 and PCIe 4.0 x16 slots for fast storage and next-gen graphics card support.
- 4 M.2 connectors, 4 SATA 6Gb/s connectors for high-speed storage options.
- Realtek® 2.5GbE LAN for fast, stable wired internet, plus Wi-Fi 7 and Bluetooth 5.4 support.
- USB4® Type-C® port and DisplayPort 2.1 for seamless video output and peripheral connectivity.
- 7.1-channel high-definition audio for immersive sound.
- ATX form factor for ample expansion and customization options.
Description
The GIGABYTE Z890 Eagle Wi-Fi 7 LGA 1851 ATX motherboard is designed for Intel® Core™ Ultra Processors, offering the ultimate combination of performance and expansion options. Featuring the Intel® Z890 chipset, this motherboard supports DDR5 memory speeds up to 9200 MHz and provides up to 256GB of system memory through 4 DIMM slots. The advanced PCIe 5.0 x16 and PCIe 4.0 x16 slots ensure that you can take full advantage of the latest graphics cards and NVMe SSDs for high-speed data access.
For storage, it offers an array of options with multiple M.2 connectors and 4 SATA 6Gb/s connectors, providing fast and reliable storage solutions for demanding applications. The Realtek® 2.5GbE LAN chip ensures stable, high-speed wired internet connectivity, while the onboard Wi-Fi 7 module and Bluetooth 5.4 support provide cutting-edge wireless capabilities, ideal for seamless online gaming and media streaming.
Onboard graphics support Intel® HD Graphics, including DisplayPort 2.1 and USB4® connectivity, making it easy to connect to high-definition displays. Additionally, the 7.1-channel high-definition audio provided by Realtek® Audio CODEC brings an immersive audio experience. The motherboard’s ATX form factor ensures ample room for expansion and custom setups.
Whether you’re building a high-performance gaming rig, content creation workstation, or server system, the GIGABYTE Z890 Eagle Wi-Fi 7 motherboard offers exceptional versatility, performance, and connectivity to meet all your needs.
Specification | Details |
---|---|
Model | GIGABYTE Z890 Eagle Wi-Fi 7 |
Socket | LGA 1851, supports Intel® Core™ Ultra Processors |
Chipset | Intel® Z890 Express Chipset |
Memory | Supports DDR5 memory up to 9200 MHz (O.C.), 4 x DIMM slots, up to 256GB |
Expansion Slots | 1 x PCIe 5.0 x16, 2 x PCIe 4.0 x16 (x4) |
Storage Interface | 1 x PCIe 5.0 x4 M.2, 2 x PCIe 4.0 x4 M.2, 1 x PCIe 4.0 x4 M.2, 4 x SATA 6Gb/s connectors |
LAN | Realtek® 2.5GbE LAN |
Wireless | MediaTek Wi-Fi 7 MT7925, Bluetooth 5.4, 2.4/5/6 GHz bands |
USB Ports | 1 x USB4® USB Type-C®, 1 x USB Type-C® (Gen 2), 2 x USB 3.2 Gen 2 Type-A, 5 x USB 3.2 Gen 1, 8 x USB 2.0/1.1 |
Audio | Realtek® Audio CODEC, 7.1-channel High Definition Audio |
Onboard Graphics | Integrated Intel® HD Graphics with DisplayPort 2.1, USB4® port |
Form Factor | ATX, 30.5cm x 24.4cm |
Operating System | Windows 11 64-bit |
Unique Features | Support for GIGABYTE Control Center, Q-Flash, Q-Flash Plus, Smart Backup |
Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
Additional information
Weight | 2.6 kg |
---|---|
Dimensions | 37 × 28 × 8 cm |
Brand | Gigabyte |
Socket | LGA 1851 CPU |
Desktop RAM | DDR5 |
