MSI MAG A500N-H 500W 80 PLUS Bronze Non-Modular Power Supply – MAG A500N-H
Original price was: ₱2,000.00.₱1,795.00Current price is: ₱1,795.00.
- 500W 80 PLUS Bronze for efficient and stable power delivery
- Non-modular design with ATX, dual EPS, PCIe, SATA, Molex, and FDD connectors
- 120mm hydraulic bearing fan for quiet and reliable cooling
- Active PFC with single 12V rail delivering up to 456W
- Industrial-grade OCP, OPP, SCP, and UVP protections
- Compact 140x150x86mm size for versatile case compatibility
- 5-year warranty for long-term reliability
In stock
Price Drop Alerts & Price History
-
Authorized
Dealer -
Nationwide
Shipping -
Store &
RMA HUB -
Expert
Support -
7-Day DOA
Protection -
Community
Trusted -
Turnstile
Protected -
reCAPTCHA
Secured -
Tested &
Verified
MSI MAG A500N-H 500W 80 PLUS Bronze Non-Modular Power Supply Product Description
Power your gaming or productivity PC with the MSI MAG A500N-H, a robust 500W 80 PLUS Bronze non-modular power supply designed for reliable performance. Featuring an active PFC and single 12V rail delivering up to 456W, it ensures stable power for mid-range systems, supporting modern CPUs and GPUs. The 120mm hydraulic bearing fan provides quiet and efficient cooling, ideal for compact builds. Industrial-grade protections, including over-current, over-power, short-circuit, and under-voltage safeguards, ensure component safety. Its compact 140x150x86mm design fits most ATX cases, while a comprehensive connector set, including dual EPS 4+4-pin, PCIe 6+2-pin, and multiple SATA and Molex connectors, supports diverse hardware configurations. With a 5-year warranty, this power supply offers dependable efficiency and durability for gamers and builders seeking a cost-effective solution for their PC builds.
| Specification | MSI MAG A500N-H |
|---|---|
| Model | MAG A500N-H |
| Modular | Non-Modular |
| Power Watt | 500W |
| Fan Size | 120 mm |
| Fan Bearing | Hydraulic Bearing |
| Dimensions (DxWxH) | 140 x 150 x 86 mm (5.51 x 5.9 x 3.38 inches) |
| PFC Type | Active PFC |
| Input Voltage Range | 200-240V~ |
| Input Frequency Range | 50~60 Hz |
| Input Current | 6.3A |
| Protection | OCP, OPP, SCP, UVP |
| DC Output | +3.3V: 14A, +5V: 14A, +12V: 38A, -12V: 0.3A, +5Vsb: 2.5A |
| Total Power | 500W (105W for +3.3V/+5V, 456W for +12V, 3.6W for -12V, 12.5W for +5Vsb) |
| Connectors | 1x ATX (24-pin), 2x EPS (4+4-pin), 1x PCI-E (6+2-pin), 3x SATA (15-pin), 2x MOLEX (4-pin), 1x FDD (4-pin) |
| Efficiency Rating | 80 PLUS Bronze |
| Weight | 1.5 kg |
|---|---|
| Dimensions | 24 × 19 × 11 cm |
| Brand | MSI |
