MSI MAG A500N-H 500W 80 PLUS Bronze Non-Modular Power Supply - MAG A500N-H
MSI MAG A500N-H 500W 80 PLUS Bronze Non-Modular Power Supply – MAG A500N-H

Original price was: ₱2,000.00.Current price is: ₱1,795.00.

In stock

Add to cart

MSI MAG A500N-H 500W 80 PLUS Bronze Non-Modular Power Supply – MAG A500N-H

Original price was: ₱2,000.00.Current price is: ₱1,795.00.

  • 500W 80 PLUS Bronze for efficient and stable power delivery
  • Non-modular design with ATX, dual EPS, PCIe, SATA, Molex, and FDD connectors
  • 120mm hydraulic bearing fan for quiet and reliable cooling
  • Active PFC with single 12V rail delivering up to 456W
  • Industrial-grade OCP, OPP, SCP, and UVP protections
  • Compact 140x150x86mm size for versatile case compatibility
  • 5-year warranty for long-term reliability

In stock

ℹ️

For walk-in customers: please always INQUIRE FIRST before visiting as not all items are displayed in our physical store. As an online-first store, most of our inventory is held in our online warehouse and is transferred to the store upon request.

Price Drop Alerts & Price History

We'll notify you the moment the price hits your target.
💡 Suggested alert: ₱1,700 [ Use this ]
Want to track and manage your alerts?
  • Authorized
    Dealer
  • Nationwide
    Shipping
  • Store &
    RMA HUB
  • Expert
    Support
  • 7-Day DOA
    Protection
  • Community
    Trusted
  • Turnstile
    Protected
  • reCAPTCHA
    Secured
  • Tested &
    Verified
Build Your Custom PC
SKU: MAG A500N-H 500W Category: Tag:

MSI MAG A500N-H 500W 80 PLUS Bronze Non-Modular Power Supply Product Description

Power your gaming or productivity PC with the MSI MAG A500N-H, a robust 500W 80 PLUS Bronze non-modular power supply designed for reliable performance. Featuring an active PFC and single 12V rail delivering up to 456W, it ensures stable power for mid-range systems, supporting modern CPUs and GPUs. The 120mm hydraulic bearing fan provides quiet and efficient cooling, ideal for compact builds. Industrial-grade protections, including over-current, over-power, short-circuit, and under-voltage safeguards, ensure component safety. Its compact 140x150x86mm design fits most ATX cases, while a comprehensive connector set, including dual EPS 4+4-pin, PCIe 6+2-pin, and multiple SATA and Molex connectors, supports diverse hardware configurations. With a 5-year warranty, this power supply offers dependable efficiency and durability for gamers and builders seeking a cost-effective solution for their PC builds.

SpecificationMSI MAG A500N-H
ModelMAG A500N-H
ModularNon-Modular
Power Watt500W
Fan Size120 mm
Fan BearingHydraulic Bearing
Dimensions (DxWxH)140 x 150 x 86 mm (5.51 x 5.9 x 3.38 inches)
PFC TypeActive PFC
Input Voltage Range200-240V~
Input Frequency Range50~60 Hz
Input Current6.3A
ProtectionOCP, OPP, SCP, UVP
DC Output+3.3V: 14A, +5V: 14A, +12V: 38A, -12V: 0.3A, +5Vsb: 2.5A
Total Power500W (105W for +3.3V/+5V, 456W for +12V, 3.6W for -12V, 12.5W for +5Vsb)
Connectors1x ATX (24-pin), 2x EPS (4+4-pin), 1x PCI-E (6+2-pin), 3x SATA (15-pin), 2x MOLEX (4-pin), 1x FDD (4-pin)
Efficiency Rating80 PLUS Bronze
Weight1.5 kg
Dimensions24 × 19 × 11 cm
