MSI MAG A750GN PCIE5 750W 80 PLUS Gold Non-Modular Power Supply – MAG A750GN PCIE5
Original price was: ₱5,400.00.₱4,750.00Current price is: ₱4,750.00.
- 750W 80 PLUS Gold with up to 90% efficiency for energy savings
- Non-modular with flexible flat cables for easy installation
- 120mm sleeve bearing fan for quiet cooling (<20 dBA at 70% load)
- ATX 3.1 and PCIe 5.1-ready with native 16-pin connector for RTX 40 Series GPUs
- OCP, OVP, OPP, OTP, and SCP protections with 105°C capacitor
- Connectors: ATX, dual EPS, PCIe 5.1, dual PCIe 6+2-pin, SATA, Molex
- Compact 140x150x86mm design with 7-year warranty
In stock
Price Drop Alerts & Price History
-
Authorized
Dealer -
Nationwide
Shipping -
Store &
RMA HUB -
Expert
Support -
7-Day DOA
Protection -
Community
Trusted -
Turnstile
Protected -
reCAPTCHA
Secured -
Tested &
Verified
MSI MAG A750GN PCIE5 750W 80 PLUS Gold Non-Modular Power Supply Product Description
Power your high-performance gaming or workstation PC with the MSI MAG A750GN PCIE5, a 750W 80 PLUS Gold non-modular power supply built for efficiency and future-proof compatibility. With up to 90% efficiency, it features active PFC and a full-bridge topology with DC-to-DC module for stable power delivery, supporting NVIDIA GeForce RTX 40 Series GPUs with its ATX 3.1 and PCIe 5.1-ready native 16-pin connector (450W capacity). The 120mm sleeve bearing fan ensures quiet cooling, maintaining low noise levels below 20 dBA at 70% load. Industrial-grade protections, including OCP, OVP, OPP, OTP, and SCP, safeguard components, while a 105°C main capacitor enhances reliability. Its non-modular design with flexible flat cables simplifies installation in compact 140x150x86mm ATX cases. With connectors like a 24-pin ATX, dual EPS 4+4-pin, PCIe 5.1, and dual PCIe 6+2-pin, it supports demanding setups. Backed by a 7-year warranty, this PSU is ideal for gamers and builders seeking robust performance and PCIe 5.1 compatibility.
[](https://www.msi.com/Power-Supply/MAG-A750GN-PCIE5)[](https://www.avadirect.com/MAG-A750GN-PCIE5-80-PLUS-Gold-750W-No-Modular-ATX-Power-Supply/Product/18396027)
| Specification | MSI MAG A750GN PCIE5 |
|---|---|
| Model | MAG A750GN PCIE5 |
| Efficiency Rating | 80 PLUS Gold (up to 90%) |
| Modular | No (non-modular) |
| Power Watt | 750W |
| Power Excursion | 1500W (up to 200% of rated power for 100μs) |
| Fan Size | 120 mm |
| Fan Bearing | Sleeve Bearing |
| Dimensions (DxWxH) | 140 x 150 x 86 mm (5.51 x 5.91 x 3.39 inches) |
| PFC Type | Active PFC |
| Input Voltage Range | 100~240 VAC |
| Input Frequency Range | 47~63 Hz |
| Protection | OCP, OVP, OPP, OTP, SCP |
| DC Output | +3.3V: 20A, +5V: 20A, +12V: 62.5A, -12V: 0.3A, +5Vsb: 2.5A |
| Total Power | 750W (110W for +3.3V/+5V, 750W for +12V, 3.6W for -12V, 12.5W for +5Vsb) |
| Connectors | 1x ATX (24-pin), 2x EPS (4+4-pin), 1x PCI-E 5.1 (16-pin), 2x PCI-E (6+2-pin), 4x SATA (15-pin), 2x MOLEX (4-pin) |
| Packaging Weight | 2.8 kg |
|---|---|
| Packaging Dimensions (L×W×H) | 32 × 22 × 13 cm |
| Brand | MSI |
