Maximize your system’s performance with the MSI MAG A850GL PCIE5 Power Supply Unit, designed for the most demanding PC builds. Achieving 80 PLUS Gold certification, this PSU delivers high energy efficiency, capable of reaching up to 90% under typical loads, reducing heat generation and operational costs. Its full modular cable design promotes a neat build with improved airflow. The unit’s 120 mm fan with Fluid Dynamic Bearing ensures a quiet operation and prolonged lifespan. With its compact size of 140 x 150 x 86 mm and equipped with Active PFC, it fits comfortably in various cases while providing stable power. The 850W power capacity with a 1700W power excursion capability guarantees support for high-power tasks. It boasts an extensive array of protections like OCP, OVP, OPP, OTP, SCP, and UVP to keep your system secure. Featuring a range of connectors including ATX, EPS, PCI-E 5.0, this PSU is ready to support next-generation hardware and serious gaming rigs.
| Feature | Specification |
|---|---|
| Efficiency Rating | 80 PLUS Gold (up to 90%) |
| Modular | Yes (full modular) |
| Fan Size | 120 mm |
| Fan Bearing | Fluid Dynamic Bearing |
| Dimensions (DxWxH) | 140 x 150 x 86 mm |
| PFC Type | Active PFC |
| Input Voltage Range | 100~240 VAC |
| Power Watt | 850W |
| Power Excursion | 1700W (*up to 200% of the PSU's rated power for 100μs) |
| Input Frequency Range | 47-63Hz |
| Protection | OCP / OVP / OPP / OTP / SCP / UVP |
| ATX (24 PIN) | 1 |
| EPS (4+4 PIN) | 2 |
| PCI-E 5.0 (16 PIN) | 1 (600W) |
| PCI-E (6+2 PIN) | 4 |
| SATA (15 PIN) | 8 |
| MOLEX (4 PIN) | 4 |
| FDD (4 PIN) | 1 |
| Weight | 3.1 kg |
|---|---|
| Dimensions | 24 × 32 × 15 cm |
