Seasonic B12 BM-550 550W 80+ Bronze Power Supply – A551BMAFH
In Stock
In Stock
Add to Wishlist
Add to Wishlist
- 80PLUS® Bronze certified for efficient energy use
- Semi-modular design with flat black cables for clean cable management
- 550W continuous power with 80+ Bronze efficiency rating
- Supports a wide input voltage range of 100V – 240V
- 120mm sleeve bearing fan with smart, silent fan control
- Protection features: OPP, OVP, OCP, SCP for safe operation
- 5-year warranty for reliable long-term performance
Description
The Seasonic B12 BM-550 850W 80+ Bronze Power Supply is designed for high-performance gaming PCs and workstations. It offers efficient and reliable power with an 80PLUS® Bronze certification, ensuring low energy consumption. Featuring a semi-modular design with flat black cables, this power supply ensures both excellent cable management and reliable performance. The unit also includes smart, silent fan control with a 120mm sleeve bearing fan for enhanced cooling, even under high load.
With a total continuous power of 550W and a wide input voltage range from 100V to 240V, this power supply is compatible with various setups. It includes essential protection features such as OPP, OVP, OCP, and SCP to safeguard your components. Backed by a 5-year warranty, the B12 BM-550 is an ideal choice for users looking for a reliable and efficient power solution in their PC builds.
| Specification | Details |
|---|---|
| Efficiency Rating | 80PLUS® Bronze |
| Cybenetics Efficiency Level | TBA |
| Cybenetics Noise Level | TBA |
| Form Factor | ATX/EPS |
| Dimensions | 140 × 150 × 86 mm |
| Fan Size | 120 mm |
| Fan Control | Smart and Silent Fan Control |
| Fan Bearing | Sleeve Bearing |
| Modularity | Semi-Modular |
| Cable Type | Flat Black Cables |
| Operating Temperature | 0 - 50 °C (derating from 100% to 80% from 40 °C to 50 °C linearly) |
| MTBF | 100,000 hours (excluding fan) |
| AC Input | 100 V - 240 V, 7 - 3.5 A, 50 Hz - 60 Hz |
| Protection Features | OPP, OVP, OCP, SCP |
| Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, CE, FCC |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
| Warranty | 5 Years |
| DC Output - +3.3 V | 20 A, 100 W |
| DC Output - +5 V | 20 A, 100 W |
| DC Output - +12 V | 45 A, 540 W |
| DC Output - -12 V | 0.3 A, 3.6 W |
| DC Output - +5 VSB | 2.5 A, 12.5 W |
| Total Continuous Power | 550 W |
| Cable Information - Mainboard (24/20 pins) | 550 mm, 1 connector, 1 cable attached |
| Cable Information - CPU (8/4 pins) | 600 mm, 1 connector, 2 cables attached |
| Cable Information - PCIe (8/6 pins) | 700 mm, 2 connectors, 1 cable |
| Cable Information - SATA | 720 mm, 3 connectors, 2 cables |
| Cable Information - Molex | 690 mm, 3 connectors, 1 cable |
Additional information
| Weight | 1.5 kg |
|---|---|
| Dimensions | 30 × 20 × 10 cm |
| Brand | Seasonic |
