ASUS TUF GAMING B760M-E D4 Micro-ATX Motherboard Intel B760 LGA1700 DDR4 PCIe 4.0 – c
₱9,900.00Original price was: ₱9,900.00.₱8,695.00Current price is: ₱8,695.00.
Intel B760 chipset with LGA1700 socket for 14th/13th/12th Gen Intel CPUs
4 x DDR4 DIMM slots, up to 128GB, supports XMP up to 5333MHz (OC)
PCIe 4.0 x16 slot and 2 x M.2 slots (PCIe 4.0, up to 64 Gbps)
Realtek 2.5Gb Ethernet with TUF LANGuard, Realtek 7.1 audio
6 rear USB ports (2 x USB 3.2 Gen 2), USB-C, DisplayPort/HDMI
ASUS TUF PROTECTION, Smart Fan 6, RAID 0/1/5/10, 3-year warranty
Out of stock
ℹ️
For walk-in customers: please always INQUIRE FIRST before visiting as not all items are displayed in our physical store. As an online-first store, most of our inventory is held in our online warehouse and is transferred to the store upon request.
ASUS TUF GAMING B760M-E D4 Micro-ATX Motherboard Intel B760 LGA1700 DDR4 PCIe 4.0 - c
Restock & Price Alerts
⚠️ That's a steep drop! You might be waiting a while.
We'll email you the moment this is back in stock. If you enter a target price, we'll also send you a separate alert if the price drops to your goal later!
ASUS TUF GAMING B760M-E D4 Micro-ATX Motherboard: Durable Performance for Intel LGA1700 Builds
Build a robust and budget-friendly PC with the ASUS TUF GAMING B760M-E D4, a micro-ATX motherboard designed for 14th, 13th, and 12th Gen Intel Core, Pentium Gold, and Celeron processors on the LGA1700 socket. Powered by the Intel B760 chipset, it supports up to 128GB of DDR4 memory across four DIMM slots with dual-channel architecture, Intel Extreme Memory Profile, and OptiMem II, reaching speeds up to 5333MHz with overclocking for cost-effective performance. The motherboard features a PCIe 4.0 x16 slot for modern GPUs, a secondary PCIe 4.0 x16 slot running at x4 mode, and a PCIe 4.0 x1 slot for additional expansion. Dual M.2 slots deliver up to 64 Gbps via PCIe 4.0, supporting type 2242/2260/2280 SSDs, complemented by four SATA 6Gb/s ports with RAID 0, 1, 5, and 10 support for versatile storage. Realtek 2.5Gb Ethernet with TUF LANGuard ensures reliable networking, while the Realtek 7.1 Surround Sound audio CODEC with premium capacitors and dedicated PCB layers delivers immersive sound when paired with an HD audio module. The board offers six rear USB ports, including two USB 3.2 Gen 2 Type-A and a front USB 3.2 Gen 2 Type-C connector, for high-speed connectivity. DisplayPort 1.4 and HDMI 2.1 support 4K at 60Hz for vibrant visuals. ASUS TUF PROTECTION with DIGI+ VRM, ESD Guards, and SafeSlot Core+ ensures durability, while Smart Fan 6 with hybrid fan headers and FAN STOP provides efficient cooling. Features like M.2 Q-Latch, Q-LED, and Armoury Crate with AURA Sync simplify installation and customization. With a 24.4 x 24.4 cm form factor, Windows 11 and 10 compatibility, and a 3-year warranty, the ASUS TUF GAMING B760M-E D4 is ideal for gamers and professionals seeking durable performance with cost-effective DDR4 memory.
ASUS TUF GAMING B760M-E D4 Motherboard Specifications
Specification
Details
Model
TUF GAMING B760M-E D4
CPU
Intel Socket LGA1700 for 14th, 13th, and 12th Gen Intel Core, Pentium Gold, and Celeron Processors; Supports Intel Turbo Boost Technology 2.0 and Turbo Boost Max Technology 3.0 (CPU-dependent)
1 x DisplayPort (4K@60Hz, DisplayPort 1.4); 1 x HDMI port (4K@60Hz, HDMI 2.1); Graphics specifications vary by CPU
Expansion Slots
CPU: 1 x PCIe 4.0 x16 slot; Chipset: 1 x PCIe 4.0 x16 slot (x4 mode), 1 x PCIe 4.0 x1 slot
Storage
CPU: 1 x M.2 slot (Key M, type 2242/2260/2280, PCIe 4.0 x4, up to 64 Gbps); Chipset: 1 x M.2 slot (Key M, type 2242/2260/2280, PCIe 4.0 x4, up to 64 Gbps); 4 x SATA 6Gb/s ports; Supports Intel Rapid Storage Technology SATA RAID 0/1/5/10
Ethernet
1 x Realtek 2.5Gb Ethernet, TUF LANGuard
Wireless & Bluetooth
Vertical M.2 slot (Key E, CNVi & PCIe, Wi-Fi module sold separately)
USB
Rear: 2 x USB 3.2 Gen 2 Type-A (10G), 2 x USB 3.2 Gen 1 Type-A (5G), 2 x USB 2.0 Type-A; Front: 1 x USB 3.2 Gen 2 Type-C connector (10G), 1 x USB 3.2 Gen 1 header (2 ports, 5G), 2 x USB 2.0 headers (4 ports)
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC; Supports Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192 kHz playback; Features Audio Shielding, Premium audio capacitors, Dedicated audio PCB layers; Requires HD audio module for 7.1 output
Back Panel I/O Ports
2 x USB 3.2 Gen 2 Type-A (10G), 2 x USB 3.2 Gen 1 Type-A (5G), 2 x USB 2.0 Type-A, 1 x DisplayPort, 1 x HDMI port, 1 x Realtek 2.5Gb Ethernet port, 3 x Audio jacks, 1 x Vertical M.2 slot (Key E), 1 x PS/2 Keyboard/Mouse combo port
Internal I/O Connectors
1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 2 x 4-pin Chassis Fan headers, 1 x 24-pin Main Power connector, 1 x 8-pin +12V Power connector, 1 x 4-pin +12V Power connector, 2 x M.2 slots (Key M), 4 x SATA 6Gb/s ports, 1 x USB 3.2 Gen 2 Type-C connector, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers, 3 x Addressable Gen 2 headers, 1 x AURA RGB header, 1 x Clear CMOS header, 1 x COM Port header, 1 x Front Panel Audio header (AAFP), 1 x S/PDIF Out header, 1 x 20-3 pin System Panel header with Chassis intrude function
Special Features
ASUS TUF PROTECTION: DIGI+ VRM (DrMOS), ESD Guards, TUF LANGuard, Overvoltage Protection, SafeSlot Core+, Stainless-Steel Back I/O; ASUS Q-Design: M.2 Q-Latch, Q-DIMM, Q-LED (CPU, DRAM, VGA, Boot Device), Q-Slot; ASUS Thermal Solution: Flexible M.2 heatsink, VRM heatsink; ASUS EZ DIY: ProCool, SafeDIMM; AURA Sync: AURA RGB header, Addressable Gen 2 headers
Software Features
ASUS Exclusive Software: Armoury Crate (AURA Creator, AURA Sync, Fan Xpert 2+, Power Saving, Two-Way AI Noise Cancelation), AI Suite 3 (DIGI+ VRM, PC Cleaner), TUF GAMING CPU-Z, DTS Audio Processing, Norton 360 for Gamers (60 Days Free Trial), WinRAR; UEFI BIOS: ASUS CrashFree BIOS 3, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode
BIOS
128 Mb Flash ROM, UEFI AMI BIOS
Manageability
WOL by PME, PXE
Accessories
2 x SATA 6Gb/s cables, 1 x I/O Shield, 1 x M.2 Rubber Package, 1 x M.2 SSD screw package, 1 x TUF Gaming sticker, 1 x TUF Certification card, 1 x User guide
Operating System
Windows 11, Windows 10 64-bit
Form Factor
Micro ATX Form Factor, 24.4 cm x 24.4 cm
Additional Features
Smart Fan 6 with multiple temperature sensors and hybrid fan headers with FAN STOP; M.2 Q-Latch for easy SSD installation; PCIe 4.0 x16 slot; Supports SATA RAID 0/1/5/10; Vertical M.2 Key E slot for optional Wi-Fi; 3-year warranty
Weight
1.7 kg
Dimensions
31 × 29 × 8 cm
Brand
Asus
Desktop RAM
DDR4
Socket
LGA 1700 CPU
