Intel Core Ultra 9 285 Processor 36M Cache up to 5.6 GHz 24-core – INTEL-BX80768285-99CN9F
In Stock
In Stock
Add to Wishlist
Add to Wishlist
Complete Your Build
This item: Intel Core Ultra 9 285 Processor 36M Cache up to 5.6 GHz 24-core - INTEL-BX80768285-99CN9F
In Stock
Original price was: ₱37,500.00.₱35,995.00Current price is: ₱35,995.00.
Original price was: ₱37,500.00.₱35,995.00Current price is: ₱35,995.00.
Original price was: ₱23,619.00.₱18,895.00Current price is: ₱18,895.00.
1 × Gigabyte Z890 Gaming X Wifi 7 Intel DDR5 Motherboard
In Stock
Original price was: ₱22,244.00.₱17,795.00Current price is: ₱17,795.00.
Original price was: ₱35,619.00.₱28,495.00Current price is: ₱28,495.00.
1 × Asus PRIME Z890-P WIFI-CSM Intel DDR5 Motherboard
In Stock
Original price was: ₱23,494.00.₱18,795.00Current price is: ₱18,795.00.
Original price was: ₱13,244.00.₱10,595.00Current price is: ₱10,595.00.
- 24 cores (8 performance, 16 efficient) and 24 threads with 5.6 GHz max turbo for top performance.
- 36 MB Smart Cache and 40 MB L2 Cache for fast data access and efficiency.
- Supports up to 192 GB DDR5 6400 MT/s and Intel® Graphics with 8K support.
- Intel® AI Boost NPU delivers 13 TOPS for advanced AI and machine learning tasks.
- Intel® vPro® Enterprise, security features, and 65W base power (182W turbo) for robust computing.
Description
Unlock unparalleled performance with the Intel® Core™ Ultra 9 Processor 285, a powerhouse from the Intel® Core™ Ultra Processors (Series 2) designed for desktop PCs, tablets, and workstations. Boasting 24 cores (8 performance-cores and 16 efficient-cores) and 24 threads, this processor delivers a maximum turbo frequency of 5.6 GHz, perfect for gaming, content creation, and multitasking. With a 36 MB Intel® Smart Cache, 40 MB L2 Cache, and support for up to 192 GB of DDR5 6400 MT/s memory, it ensures lightning-fast data access and efficiency. The integrated Intel® Graphics with 4 Xe-cores and a 2 GHz max dynamic frequency, combined with 13 TOPS from the Intel® AI Boost NPU, enable advanced AI capabilities and stunning visuals up to 8K. Featuring Intel® vPro® Enterprise eligibility, robust security options, and a 65W base power (up to 182W turbo), this processor is ideal for high-performance computing with future-ready features launching in Q1’25.
| Specification | Details |
|---|---|
| Product Collection | Intel® Core™ Ultra Processors (Series 2) |
| Code Name | Products formerly Arrow Lake |
| Vertical Segment | Desktop |
| Processor Number | 285 |
| Overall Peak TOPS (Int8) | 36 |
| Recommended Customer Price | $549.00-$579.00 |
| Total Cores | 24 |
| # of Performance-cores | 8 |
| # of Efficient-cores | 16 |
| Total Threads | 24 |
| Max Turbo Frequency | 5.6 GHz |
| Intel® Thermal Velocity Boost Frequency | 5.6 GHz |
| Intel® Turbo Boost Max Technology 3.0 Frequency | 5.5 GHz |
| Performance-core Max Turbo Frequency | 5.4 GHz |
| Efficient-core Max Turbo Frequency | 4.6 GHz |
| Performance-core Base Frequency | 2.5 GHz |
| Efficient-core Base Frequency | 1.9 GHz |
| Cache | 36 MB Intel® Smart Cache |
| Total L2 Cache | 40 MB |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 182 W |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| AI Software Frameworks Supported by CPU | OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
| CPU Lithography | TSMC N3B |
| Marketing Status | Launched |
| Launch Date | Q1'25 |
| Embedded Options Available | Yes |
| Use Conditions | PC/Client/Tablet, Workstation |
| Max Memory Size | 192 GB |
| Memory Types | Up to DDR5 6400 MT/s |
| Max # of Memory Channels | 2 |
| ECC Memory Supported | Yes |
| GPU Name | Intel® Graphics |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 2 GHz |
| GPU Peak TOPS (Int8) | 8 |
| Graphics Output | DP2.1 UHBR20, HDMI 2.1 FRL 12GHz, eDP 1.4b |
| Xe-cores | 4 |
| Max Resolution (HDMI) | 4K @ 60Hz (HDMI 2.1 TMDS), 8K @ 60Hz (HDMI 2.1 FRL) |
| Max Resolution (DP) | 8K @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 4K @ 60Hz |
| DirectX Support | 12 |
| OpenGL Support | 4.5 |
| OpenCL Support | 3 |
| Intel® Quick Sync Video | Yes |
| # of Displays Supported | 4 |
| Device ID | 0x7D67 |
| Intel® Deep Learning Boost (Intel® DL Boost) on GPU | Yes |
| NPU Name | Intel® AI Boost |
| NPU Peak TOPS (Int8) | 13 |
| Sparsity Support | Yes |
| Windows Studio Effects Support | Yes |
| AI Software Frameworks Supported by NPU | OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
| Direct Media Interface (DMI) Revision | 4 |
| Max # of DMI Lanes | 8 |
| Intel® Thunderbolt™ 4 | Yes |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations | Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 |
| Max # of PCI Express Lanes | 24 |
| Sockets Supported | FCLGA1851 |
| Thermal Solution Specification | PCG 2022C |
| Max Operating Temperature | 105 °C |
| Intel® Volume Management Device (VMD) | Yes |
| Intel® Gaussian & Neural Accelerator | 3.5 |
| Intel® Thread Director | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Thermal Velocity Boost | Yes |
| Intel® Turbo Boost Max Technology 3.0 | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel vPro® Eligibility | Intel vPro® Enterprise |
| Intel® Threat Detection Technology (TDT) | Yes |
| Intel® Active Management Technology (AMT) | Yes |
| Intel® Standard Manageability (ISM) | Yes |
| Intel® Remote Platform Erase (RPE) | Yes |
| Intel® One-Click Recovery | Yes |
| Intel® Control-Flow Enforcement Technology | Yes |
| Intel® Total Memory Encryption - Multi Key | Yes |
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® OS Guard | Yes |
| Intel® Boot Guard | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| Intel® Stable IT Platform Program (SIPP) | Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
Additional information
| Weight | 0.5 kg |
|---|---|
| Dimensions | 12 × 12 × 10 cm |
| Brand | Intel |
| Socket | LGA 1851 CPU |
