Colorful Battle-AX B650M Plus V14 Micro ATX Motherboard w/ AM5 Socket, DDR5 Support


- Compatible with AMD Ryzen™ 7000 Series processors using the AM5 socket for maximum performance.
- Supports up to 128GB of DDR5 memory with speeds up to 6400 MHz (OC) for rapid multitasking.
- Features 1 x PCIe 4.0 x16 for GPU, 1 x PCIe 4.0 x4, and 2 x M.2 slots for fast storage solutions.
- Includes HDMI and DisplayPort outputs, perfect for high-quality visuals on modern monitors.
- Equipped with 4 x USB 3.2 Gen 1, USB Type-C, and USB 2.0 ports for versatile connectivity.
- Enhanced 7.1 channel HD audio with Realtek ALC897 codec for immersive sound.
- Supports overclocking, smart fan control, and RGB/ARGB customization for a unique build.
- Compact Micro ATX design (244 mm x 244 mm), ideal for smaller cases and builds.
Description
The Colorful Battle-AX B650M Plus V14 Micro ATX Motherboard is a performance-driven motherboard designed for AMD Ryzen™ 7000 Series processors, featuring the AM5 socket and the powerful AMD B650 chipset. Whether you’re assembling a high-performance gaming rig or a versatile workstation, this motherboard offers everything you need for exceptional computing power and expandability.
Equipped with four DDR5 DIMM slots, the Battle-AX B650M Plus V14 supports up to 128GB of memory at speeds of up to 6400 MHz (OC), enabling ultra-fast performance for demanding applications. The dual-channel memory architecture enhances data throughput, delivering smooth multitasking and quick load times for games and productivity software.
This motherboard offers ample storage options, including an M.2 PCIe 4.0 x4 NVMe slot and four SATA III ports for high-speed storage devices. You can also benefit from enhanced graphics support with PCIe 4.0 x16 slots for the latest GPUs. Whether for gaming, content creation, or other intensive tasks, you’ll enjoy improved loading times and graphical performance.
Networking is a breeze with the built-in Gigabit LAN port, ensuring stable internet connectivity, while the audio system delivers high-definition 7.1 surround sound with Realtek ALC897. For visual output, this motherboard includes HDMI and DisplayPort connectors, supporting modern displays and multi-monitor setups.
With a focus on cooling and performance, the Battle-AX B650M Plus V14 offers four fan headers and support for ARGB and RGB lighting, enabling customization and efficient heat dissipation. With its 8+2 DrMOS power phases, the motherboard ensures stable and reliable power delivery even under heavy loads.
Designed for future-proofing and performance, the Colorful Battle-AX B650M Plus V14 Micro ATX Motherboard is ideal for those seeking top-tier functionality, overclocking potential, and a sleek design. It’s the perfect choice for building powerful, next-generation systems.
Specification | Details |
---|---|
Form Factor | MicroATX |
Chipset | AMD B650 |
CPU Socket | AM5 |
Supported CPUs | AMD Ryzen™ 7000 Series Processors |
Memory Support | DDR5, Dual Channel |
Memory Slots | 4 x DIMM Slots |
Maximum Memory Capacity | Up to 128GB DDR5 |
Memory Speed | Supports DDR5 speeds up to 6400 MHz (OC) |
PCIe Slots | 1 x PCIe 4.0 x16 (for GPU), 1 x PCIe 4.0 x4 |
Storage Interface | 1 x M.2 PCIe 4.0 x4 (NVMe), 4 x SATA III |
USB Ports | 4 x USB 3.2 Gen 1 (Type-A), 1 x USB 3.2 Gen 1 (Type-C), 4 x USB 2.0 |
Networking | 1 x Gigabit LAN |
Audio | 7.1 Channel High Definition Audio (Realtek ALC897 Codec) |
Display Output | 1 x HDMI, 1 x DisplayPort |
Expansion Slots | 2 x M.2 Slots (1 x PCIe 4.0, 1 x PCIe 3.0) |
Fan Headers | 4 x Fan Headers |
BIOS | UEFI BIOS |
Power Phases | 8+2 DrMOS Power Phases |
RGB/ARGB Support | 1 x 5V ARGB Header, 1 x 12V RGB Header |
Rear I/O | 1 x HDMI, 1 x DisplayPort, 1 x LAN Port, 1 x USB Type-C, 4 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0, Audio Jacks (Line-Out, Mic-In, Line-In) |
Other Features | Overclocking Support, EZ Debug LED, Smart Fan Control |
Dimensions | 244 mm x 244 mm |
Operating System Support | Windows 10, Windows 11 |
Additional information
Weight | 1.7 kg |
---|---|
Dimensions | 31 × 29 × 8 cm |
Brand | Colorful |
Socket | AM5 CPU |
Desktop RAM | DDR5 |
